Running AutoGrad on GPU
Table of contents
Post
In the previous post I’ve implemented an MLP image encoder using the toy AutoGrad framework. In this post I will add a simple naive GPU inference and backpropagation runtime. The goal is a theoretic excercise rather than optimizations, at first. Naive implementation doesn’t run faster on a GPU because of excessive memory transfers, command queue flushes, dynamic memory allocation and lack of a good parallel scheduler for the compute graph.
For implementation I’m going to be using PyOpenCL. OpenCL is quite old and not widely used for ultra performance, but it’s still somewhat portable across different platforms. The only issue is I’m not sure what’s the status of fp32 atomics and support for lower bit types that we all love(fp16, fp8 e4m3).
First off we’d need to implement all the kernels for common operations: Add, Mul, Div, MatrixMultiply, OuterProduct etc. Then we just replace numpy arrays with cl.Buffers and then for each operation during _materialize() we simply dispatch a kernel in eager mode, meaning that we just dispatch as we go without fusing/scheduling. Also we allocate a new buffer on each operation dynamically, which obviously murders the performance - but that’s fine for a first functional implementation.
Also what helped quite a bit is to maintain a cpu fallback for the operations such that we can debug and A/B test in case there’s something guffy.
I’m providing the code as is along with the tests, which are required to get anything at all functional on a GPU because we don’t have a debugger. So as many tests as possible help catch issues early.
Source Code:
import math
import random
from matplotlib import image
import numpy as np
import ctypes
import pyopencl as cl
import os
os.environ["PYOPENCL_CTX"] = "0"
TERMINAL_COLOR_GREEN = "\033[32m"
TERMINAL_COLOR_RED = "\033[31m"
TERMINAL_COLOR_RESET = "\033[0m"
DEBUG_CPU_EMULATION = 0
ctx = cl.create_some_context()
queue = cl.CommandQueue(ctx)
def dims_get_total(dims):
total = 1
for d in dims:
total *= d
return total
free_tensor_pool = {}
allocated_tensor_pool = {}
def get_number_of_allocated_buffers():
return sum(len(buffs) for buffs in allocated_tensor_pool.values())
def get_number_of_free_buffers():
return sum(len(buffs) for buffs in free_tensor_pool.values())
def make_array(shape):
size = dims_get_total(shape) * 4
# if size in free_tensor_pool and len(free_tensor_pool[size]) > 0:
# # print("Reusing buffer of size:", size)
# return free_tensor_pool[size].pop()
buf = cl.Buffer(ctx, cl.mem_flags.READ_WRITE, size=size)
# allocated_tensor_pool[size] = allocated_tensor_pool.get(size, []) + [buf]
return buf
def free_all_buffers():
for size, buffs in allocated_tensor_pool.items():
for buf in buffs:
free_buffer(buf, size)
def free_buffer(buffer, size_in_bytes):
if size_in_bytes not in free_tensor_pool:
free_tensor_pool[size_in_bytes] = []
if not buffer in free_tensor_pool[size_in_bytes]:
free_tensor_pool[size_in_bytes].append(buffer)
def download_from_gpu(buffer, shape):
result = np.empty(dims_get_total(shape), dtype=np.float32)
cl.enqueue_copy(queue, result, buffer)
return result.reshape(shape)
def upload_to_gpu(array, buffer):
cl.enqueue_copy(queue, buffer, array)
def make_gpu_buffer_from_numpy(array):
buffer = make_array(array.shape)
upload_to_gpu(array, buffer)
return buffer
prg = cl.Program(ctx, """
//js
#define f32 float
#define i32 int
#define u32 unsigned int
#define ifor(N) for (i32 i = 0; i < (int)(N); ++i)
#define jfor(N) for (i32 j = 0; j < (int)(N); ++j)
__kernel void max(
__global f32 *dst,
__global const f32 *a,
__global const f32 *b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] > b[gid] ? a[gid] : b[gid];
}
}
__kernel void min(
__global f32 *dst,
__global const f32 *a,
__global const f32 *b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] < b[gid] ? a[gid] : b[gid];
}
}
__kernel void leaky_relu(
__global f32 *dst,
__global const f32 *a,
const f32 negative_slope,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = max(a[gid], negative_slope * a[gid]);
}
}
__kernel void leaky_relu_grad(
__global f32 *dst,
__global const f32 *a,
const f32 negative_slope,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] < 0.0f ? negative_slope : 1.0f;
}
}
__kernel void add(
__global f32 *dst,
__global const f32 *a,
__global const f32 *b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] + b[gid];
}
}
__kernel void sub(
__global f32 *dst,
__global const f32 *a,
__global const f32 *b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] - b[gid];
}
}
__kernel void mul(
__global f32 *dst,
__global const f32 *a,
__global const f32 *b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] * b[gid];
}
}
__kernel void div(
__global f32 *dst,
__global const f32 *a,
__global const f32 *b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] / b[gid];
}
}
__kernel void abs(
__global f32 *dst,
__global const f32 *a,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = fabs(a[gid]);
}
}
__kernel void sign(
__global f32 *dst,
__global const f32 *a,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] < 0.0f ? -1.0f : (a[gid] > 0.0f ? 1.0f : 0.0f);
}
}
__kernel void sqrt_kernel(
__global f32 *dst,
__global const f32 *a,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = sqrt(a[gid]);
}
}
__kernel void addf(
__global f32 *dst,
__global const f32 *a,
const f32 b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] + b;
}
}
__kernel void add_first_elem(
__global f32 *dst, // layout [B, N]
__global const f32 *a, // layout [B, N]
__global const f32 *b, // layout [B, 1]
const i32 B,
const i32 N)
{
const i32 gid = get_global_id(0);
const i32 bid = gid / N;
if (gid < (B * N)) {
dst[gid] = a[gid] + b[bid];
}
}
__kernel void broadcast_add_kernel(
__global f32 *dst, // layout [N]
__global const f32 *a, // layout [N]
__global const f32 *b, // layout [1]
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] + b[0];
}
}
__kernel void subf(
__global f32 *dst,
__global const f32 *a,
const f32 b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] - b;
}
}
__kernel void mulf(
__global f32 *dst,
__global const f32 *a,
const f32 b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] * b;
}
}
__kernel void divf(
__global f32 *dst,
__global const f32 *a,
const f32 b,
const i32 N)
{
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = a[gid] / b;
}
}
// https://ingowald.blog/2018/06/24/float-atomics-in-opencl/
// https://streamhpc.com/blog/2016-02-09/atomic-operations-for-floats-in-opencl-improved/
static void atomicAdd_g_f(volatile __global float *addr, float val)
{
union {
unsigned int u;
float f;
} next, expected, current;
current.f = *addr;
do {
expected.f = current.f;
next.f = expected.f + val;
current.u = atomic_cmpxchg( (volatile __global unsigned int *)addr, expected.u, next.u);
} while( current.u != expected.u );
}
// Reduce by locally sum 64 elements and then do 1 atomic add
__kernel void reduce_64(
__global f32 *dst,
__global const f32 *src,
const i32 N)
{
const i32 gid = 64 * get_global_id(0);
f32 acc = (f32)(0.0);
ifor(64) {
const i32 idx = gid + i;
if (idx < N) {
acc += src[idx];
}
}
if (gid < N) {
atomicAdd_g_f(&dst[0], acc);
}
}
// matmul (N, C) by (F, C)
__kernel void matmul(
__global f32 *dst, // layout = [N, F]
__global const f32 *src, // layout = [N, C]
__global const f32 *mat, // layout = [F, C]
const i32 N,
const i32 C,
const i32 F
) {
const i32 gid = get_global_id(0);
const i32 nidx = gid / F;
const i32 fidx = gid % F;
if (gid < (N * F)) {
f32 acc = (f32)(0.0);
ifor(C) {
acc += src[nidx * C + i] * mat[fidx * C + i];
}
dst[gid] = acc;
}
}
__kernel void outer_product_accumulate(
__global f32 *dst, // layout = [F, C]
__global const f32 *a, // layout = [N, C]
__global const f32 *b, // layout = [N, F]
const i32 N,
const i32 C,
const i32 F
) {
const i32 gid = get_global_id(0);
const i32 fidx = gid / C;
const i32 cidx = gid % C;
if (gid < (C * F)) {
f32 acc = (f32)(0.0);
ifor(N) {
acc += a[i * C + cidx] * b[i * F + fidx];
}
atomicAdd_g_f(&dst[gid], acc);
}
}
__kernel void zero(
__global f32 *dst,
const i32 N
) {
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = 0.0f;
}
}
__kernel void set(
__global f32 *dst,
const f32 val,
const i32 N
) {
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid] = val;
}
}
__kernel void copy(
__global f32 *dst,
const i32 dst_offset_elems,
__global const f32 *src,
const i32 src_offset_elems,
const i32 N
) {
const i32 gid = get_global_id(0);
if (gid < N) {
dst[gid + dst_offset_elems] = src[gid + src_offset_elems];
}
}
__kernel void transpose(
__global f32 *dst, // layout = [C, F]
__global const f32 *src, // layout = [F, C]
const i32 F,
const i32 C
) {
const i32 gid = get_global_id(0);
const i32 fidx = gid / C;
const i32 cidx = gid % C;
if (gid < (F * C)) {
dst[cidx * F + fidx] = src[gid];
}
}
// https://github.com/skeeto/hash-prospector
static uint lowbias32(uint x)
{
x ^= x >> 16;
x *= 0x7feb352d;
x ^= x >> 15;
x *= 0x846ca68b;
x ^= x >> 16;
return x;
}
typedef struct {
f32 x;
f32 y;
} f32x2;
static f32x2 make_f32x2(f32 x, f32 y) {
f32x2 result;
result.x = x;
result.y = y;
return result;
}
static f32x2 random_f32x2(uint *seed) {
*seed = lowbias32(*seed);
return make_f32x2((f32)(*seed & 0xFFFF) / 0xFFFF, (f32)((*seed >> 16) & 0xFFFF) / 0xFFFF);
}
// https://gpuopen.com/learn/sampling-normal-gaussian-distribution-gpus/
#define TWO_PI (6.283185307179586476925286766559f)
static f32x2 sampleGaussBoxMuller(f32x2 u, float mean, float standardDeviation)
{
const float a = standardDeviation * sqrt(-2.0f * log(1.0f - u.x));
const float b = TWO_PI * u.y;
return (f32x2){cos(b) * a + mean, sin(b) * a + mean};
}
static f32 SampleGaussian(uint *seed, const f32 mean, const f32 variance) {
f32x2 u = random_f32x2(seed);
return sampleGaussBoxMuller(u, mean, sqrt(variance)).x;
}
__kernel void set_gaussian(
__global f32 *dst,
const f32 mean,
const f32 variance,
const u32 rseed,
const i32 N
) {
const i32 gid = get_global_id(0);
u32 seed = lowbias32(rseed + lowbias32(gid));
if (gid < N) {
dst[gid] = SampleGaussian(&seed, mean, variance);
}
}
__kernel void reduce_broadcast(
__global f32 *dst, // [B, N]
__global f32 const *src, // [B, M, N]
const i32 B,
const i32 M,
const i32 N
) {
const i32 gid = get_global_id(0);
const i32 bid = gid / (N);
const i32 nid = gid % (N);
if (gid < (B * N)) {
f32 acc = 0.0f;
ifor(M) {
acc += src[bid * M * N + i * N + nid];
}
dst[gid] = acc;
}
}
;//
""").build()
assert prg is not None
def roundup_to_64(x): return ((int(math.ceil(x)) + 63) // 64) * 64
_add_kernel = prg.add
_sub_kernel = prg.sub
_mul_kernel = prg.mul
_div_kernel = prg.div
_abs_kernel = prg.abs
_sign_kernel = prg.sign
_sqrt_kernel = prg.sqrt_kernel
_addf_kernel = prg.addf
_add_first_elem_kernel = prg.add_first_elem
_subf_kernel = prg.subf
_mulf_kernel = prg.mulf
_divf_kernel = prg.divf
_reduce_64_kernel = prg.reduce_64
_matmul_kernel = prg.matmul
_outer_product_accumulate_kernel = prg.outer_product_accumulate
_transpose_kernel = prg.transpose
_zero_kernel = prg.zero
_set_kernel = prg.set
_set_gaussian_kernel = prg.set_gaussian
_min_kernel = prg.min
_max_kernel = prg.max
_leaky_relu_grad_kernel = prg.leaky_relu_grad
_leaky_relu_kernel = prg.leaky_relu
_copy_kernel = prg.copy
_reduce_broadcast_kernel = prg.reduce_broadcast
_broadcast_add_kernel = prg.broadcast_add_kernel
def add_kernel(dst, a, b, N): _add_kernel(queue, [roundup_to_64(N)], None, dst, a, b, np.array([N], dtype=np.int32))
def sub_kernel(dst, a, b, N): _sub_kernel(queue, [roundup_to_64(N)], None, dst, a, b, np.array([N], dtype=np.int32))
def mul_kernel(dst, a, b, N): _mul_kernel(queue, [roundup_to_64(N)], None, dst, a, b, np.array([N], dtype=np.int32))
def div_kernel(dst, a, b, N): _div_kernel(queue, [roundup_to_64(N)], None, dst, a, b, np.array([N], dtype=np.int32))
def abs_kernel(dst, a, N): _abs_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([N], dtype=np.int32))
def sign_kernel(dst, a, N): _sign_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([N], dtype=np.int32))
def sqrt_kernel(dst, a, N): _sqrt_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([N], dtype=np.int32))
def addf_kernel(dst, a, b, N): _addf_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([b], dtype=np.float32), np.array([N], dtype=np.int32))
def add_first_elem_kernel(dst, a, b, B, N): _add_first_elem_kernel(queue, [roundup_to_64(B * N)], None, dst, a, b, np.array([B], dtype=np.int32), np.array([N], dtype=np.int32))
def broadcast_add_kernel(dst, a, b, N): _broadcast_add_kernel(queue, [roundup_to_64(N)], None, dst, a, b, np.array([N], dtype=np.int32))
def subf_kernel(dst, a, b, N): _subf_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([b], dtype=np.float32), np.array([N], dtype=np.int32))
def mulf_kernel(dst, a, b, N): _mulf_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([b], dtype=np.float32), np.array([N], dtype=np.int32))
def divf_kernel(dst, a, b, N): _divf_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([b], dtype=np.float32), np.array([N], dtype=np.int32))
def reduce_kernel(dst, src, N): _reduce_64_kernel(queue, [roundup_to_64(N / 64)], None, dst, src, np.array([N], dtype=np.int32))
def matmul_kernel(dst, a, b, N, C, F): _matmul_kernel(queue, [roundup_to_64(N * F)], None, dst, a, b, np.array([N], dtype=np.int32), np.array([C], dtype=np.int32), np.array([F], dtype=np.int32))
def outer_product_accumulate_kernel(dst, a, b, N, C, F): _outer_product_accumulate_kernel(queue, [roundup_to_64(F * C)], None, dst, a, b, np.array([N], dtype=np.int32), np.array([C], dtype=np.int32), np.array([F], dtype=np.int32))
def transpose_kernel(dst, src, F, C): _transpose_kernel(queue, [roundup_to_64(F * C)], None, dst, src, np.array([F], dtype=np.int32), np.array([C], dtype=np.int32))
def set_kernel(dst, val, N): _set_kernel(queue, [roundup_to_64(N)], None, dst, np.array([val], dtype=np.float32), np.array([N], dtype=np.int32))
def zero_kernel(dst, N): _zero_kernel(queue, [roundup_to_64(N)], None, dst, np.array([N], dtype=np.int32))
def set_gaussian_kernel(dst, mean, variance, seed, N): _set_gaussian_kernel(queue, [roundup_to_64(N)], None, dst, np.array([mean], dtype=np.float32), np.array([variance], dtype=np.float32), np.array([seed], dtype=np.int32), np.array([N], dtype=np.int32))
def min_kernel(dst, a, b, N): _min_kernel(queue, [roundup_to_64(N)], None, dst, a, b, np.array([N], dtype=np.int32))
def max_kernel(dst, a, b, N): _max_kernel(queue, [roundup_to_64(N)], None, dst, a, b, np.array([N], dtype=np.int32))
def leaky_relu_grad_kernel(dst, a, negative_slope, N): _leaky_relu_grad_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([negative_slope], dtype=np.float32), np.array([N], dtype=np.int32))
def leaky_relu_kernel(dst, a, negative_slope, N): _leaky_relu_kernel(queue, [roundup_to_64(N)], None, dst, a, np.array([negative_slope], dtype=np.float32), np.array([N], dtype=np.int32))
def copy_kernel(dst, dst_offset_elems, src, src_offset_elems, N): _copy_kernel(queue, [roundup_to_64(N)], None, dst, np.array([dst_offset_elems], dtype=np.int32), src, np.array([src_offset_elems], dtype=np.int32), np.array([N], dtype=np.int32))
def reduce_broadcast(dst, src, B, M, N): _reduce_broadcast_kernel(queue, [roundup_to_64(B * N)], None, dst, src, np.array([B], dtype=np.int32), np.array([M], dtype=np.int32), np.array([N], dtype=np.int32))
"""
New basic building block class for compute.
Basically a flat array with a rule for accessing elements.
We're using a basic rule of linear strides.
"""
class Tensor:
def __init__(self, shape, data=None):
self.shape = list(shape)
if data is not None:
if isinstance(data, list):
data = np.array(data, dtype=np.float32)
assert dims_get_total(shape) == dims_get_total(list(data.shape)), f"Data shape {data.shape} does not match tensor shape {shape}"
assert isinstance(data, np.ndarray), f"Data must be a numpy array, got {type(data)}"
data = data.astype(np.float32)
self.buffer = make_gpu_buffer_from_numpy(data)
else:
self.buffer = make_array(shape)
zero_kernel(self.buffer, dims_get_total(shape))
self.strides = []
self._compute_strides()
def download(self): return download_from_gpu(self.buffer, self.shape)
def _compute_strides(self):
total = 1
for d in reversed(self.shape):
self.strides.insert(0, total)
total *= d
def _get_flat_index(self, indices):
if len(indices) != len(self.shape):
raise ValueError("Incorrect number of indices")
index = 0
for i, idx in enumerate(indices):
if not (0 <= idx < self.shape[i]):
raise IndexError("Index out of bounds")
index += idx * self.strides[i]
return index
def __repr__(self):
return f"Tensor(shape={self.shape})"
def __add__(self, other):
result = Tensor(self.shape)
if isinstance(other, (int, float)):
addf_kernel(result.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
add_kernel(result.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return result
def __iadd__(self, other):
if isinstance(other, (int, float)):
addf_kernel(self.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
add_kernel(self.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return self
def __mul__(self, other):
result = Tensor(self.shape)
if isinstance(other, (int, float)):
mulf_kernel(result.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
mul_kernel(result.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return result
def __iadd__(self, other):
if isinstance(other, (int, float)):
addf_kernel(self.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
add_kernel(self.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return self
def __sub__(self, other):
result = Tensor(self.shape)
if isinstance(other, (int, float)):
subf_kernel(result.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
sub_kernel(result.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return result
def __isub__(self, other):
if isinstance(other, (int, float)):
subf_kernel(self.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
sub_kernel(self.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return self
def __truediv__(self, other):
result = Tensor(self.shape)
if isinstance(other, (int, float)):
divf_kernel(result.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
div_kernel(result.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return result
def __itruediv__(self, other):
if isinstance(other, (int, float)):
divf_kernel(self.buffer, self.buffer, other, dims_get_total(self.shape))
else:
assert self.shape == other.shape, f"Shapes {self.shape} and {other.shape} must match"
div_kernel(self.buffer, self.buffer, other.buffer, dims_get_total(self.shape))
return self
def abs(self):
result = Tensor(self.shape)
abs_kernel(result.buffer, self.buffer, dims_get_total(self.shape))
return result
def sqrt(self):
result = Tensor(self.shape)
sqrt_kernel(result.buffer, self.buffer, dims_get_total(self.shape))
return result
if 1: # tests
#########
# TESTS #
#########
a = make_gpu_buffer_from_numpy(np.array([1, 1, 1, 1], dtype=np.float32))
b = make_gpu_buffer_from_numpy(np.array([1, 1, 1, 2], dtype=np.float32))
c = make_array((4,))
add_kernel(c, a, b, a.size)
d = make_array((4,))
reduce_kernel(d, c, a.size)
b = download_from_gpu(d, (1,))
# print(b)
assert b[0] == 9.0, f"Reduction result is wrong! {b[0]} vs 9.0"
N = 4
C = 4
F = 8
np_a = np.random.rand(N, C).astype(np.float32)
np_mat = np.random.rand(F, C).astype(np.float32)
np_result = np.einsum("nc, fc -> nf", np_a, np_mat)
a = make_gpu_buffer_from_numpy(np_a)
mat = make_gpu_buffer_from_numpy(np_mat)
c = make_array((N, F))
matmul_kernel(c, a, mat, N, C, F)
b = download_from_gpu(c, (N, F))
assert (np.abs(b - np_result) < 1e-4).all(), f"Results do not match! {b} vs {np_result}"
free_all_buffers()
# outer product accumulation
N = 4
C = 4
F = 8
np_a = np.random.rand(N, C).astype(np.float32)
np_b = np.random.rand(N, F).astype(np.float32)
np_result = np.einsum("nc, nf -> fc", np_a, np_b)
a = make_gpu_buffer_from_numpy(np_a)
b = make_gpu_buffer_from_numpy(np_b)
c = make_array((F, C))
zero_kernel(c, F * C)
outer_product_accumulate_kernel(c, a, b, N, C, F)
b = download_from_gpu(c, (F, C))
assert (np.abs(b - np_result) < 1e-4).all(), f"Results do not match!\n{b}\n vs\n{np_result}\n"
free_all_buffers()
# transpose
np_mat = np.random.rand(F, C).astype(np.float32)
np_result = np_mat.T
a = make_gpu_buffer_from_numpy(np_mat)
c = make_array((C, F))
zero_kernel(c, F * C)
transpose_kernel(c, a, F, C)
b = download_from_gpu(c, (C, F))
assert (np.abs(b - np_result) < 1e-4).all(), f"Results do not match! {b} vs {np_result}"
free_all_buffers()
B = 32
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
assert (np.abs(b.download() - np_b) < 1e-4).all(), f"Tensor download failed! {b.download()} vs {np_b}"
assert (np.abs(a.download() - np_a) < 1e-4).all(), f"Tensor download failed! {a.download()} vs {np_a}"
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() + b.download()
c = a + b
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor addition failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() - b.download()
c = a - b
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor subtraction failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() * b.download()
c = a * b
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor multiplication failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16) * 16.0
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() / b.download()
c = a / b
assert (np.abs(c.download() - ref) < 1e-3).all(), f"Tensor division failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() + 0.777
c = a + 0.777
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor addition failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() - 0.777
c = a - 0.777
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor subtraction failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() * 0.777
c = a * 0.777
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor multiplication failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
np_b = np.random.rand(B, 16)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
ref = a.download() / 0.777
c = a / 0.777
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor division failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.rand(B, 16)
ref = np.abs(np_a)
a = Tensor(shape=[B, 16], data=np_a)
c = a.abs()
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor absolute failed! {c.download()} vs {ref}"
E = 7
np_a = np.random.rand(B, 16)
ref = np.ndarray((B, E * 16))
for i in range(E):
for j in range(16):
ref[:, i * 16 + j] = np_a[:, j]
a = Tensor(shape=[B, 16], data=np_a)
c = Tensor(shape=[B, 16 * E])
for b in range(B):
for i in range(16): # Clone the tensor N times
copy_kernel(c.buffer, b * 16 * E + i * 16, a.buffer, b * 16, 16)
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor broadcast failed! {c.download()} vs {ref}"
ref_reduce = np.zeros((B, 16))
for b in range(B):
for i in range(E):
for j in range(16):
ref_reduce[b, j] += ref[b, i * 16 + j]
b = Tensor(shape=[B, 16])
reduce_broadcast(b.buffer, c.buffer, B, E, 16)
assert (np.abs(b.download() - ref_reduce) < 1e-4).all(), f"Tensor reduction failed! {b.download()} vs {ref_reduce}"
free_all_buffers()
np_a = np.random.normal(0, 1, (B, 16))
np_b = np.random.normal(0, 1, (B, 1))
ref = np.zeros((B, 16))
for b in range(B):
ref[b] = np_a[b] + np_b[b]
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 1], data=np_b)
c = Tensor(shape=[B, 16])
add_first_elem_kernel(c.buffer, a.buffer, b.buffer, B, 16)
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor addition with first elem failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.normal(0, 1, (B, 16))
ref = np.sqrt(np.abs(np_a))
a = Tensor(shape=[B, 16], data=np_a)
c = Tensor(shape=[B, 16])
abs_kernel(c.buffer, a.buffer, B * 16)
sqrt_kernel(c.buffer, c.buffer, B * 16)
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor sqrt failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.normal(0, 1, (B, 16))
ref = np.maximum(np_a, 0.1 * np_a)
a = Tensor(shape=[B, 16], data=np_a)
c = Tensor(shape=[B, 16])
leaky_relu_kernel(c.buffer, a.buffer, 0.1, B * 16)
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor leaky_relu failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.normal(0, 1, (B, 16))
ref = np.where(np_a > 0, 1.0, 0.1)
a = Tensor(shape=[B, 16], data=np_a)
c = Tensor(shape=[B, 16])
leaky_relu_grad_kernel(c.buffer, a.buffer, 0.1, B * 16)
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor leaky_relu failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.normal(0, 1, (B, 16))
ref = np.where(np_a > 0, 1.0, 0.1)
a = Tensor(shape=[B, 16], data=np_a)
c = Tensor(shape=[B, 16])
set_kernel(c.buffer, 777.0, B * 16)
ref = np.full((B, 16), 777.0, dtype=np.float32)
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor set failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.normal(0, 1, (B, 16))
np_b = np.random.normal(0, 1, (B, 16))
ref = np_a / (np_b + 1.0e-6)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
c = a / (b + 1.0e-6)
assert (np.abs(c.download() - ref) < 1e-3).all(), f"Tensor failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.normal(0, 1, (B, 16))
np_b = np.random.normal(0, 1, (B, 16))
ref = np_a / (np.sqrt(np.abs(np_b)) + 1.0e-6)
a = Tensor(shape=[B, 16], data=np_a)
b = Tensor(shape=[B, 16], data=np_b)
c = a / (b.abs().sqrt() + 1.0e-6)
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor failed! {c.download()} vs {ref}"
free_all_buffers()
np_a = np.random.normal(0, 1, (16, 16))
np_b = np.random.normal(0, 1, (16, 16))
np_c = np.random.normal(0, 1, (16, 16))
ref = np_a / (np.sqrt(np.abs(np_b)) + 1.0e-6) - np_c * 0.001
a = Tensor(shape=[16, 16], data=np_a)
b = Tensor(shape=[16, 16], data=np_b)
c = Tensor(shape=[16, 16], data=np_c)
c = a / (b.abs().sqrt() + 1.0e-6) - c * 0.001
assert (np.abs(c.download() - ref) < 1e-4).all(), f"Tensor failed! {c.download()} vs {ref}"
free_all_buffers()
print(f"{TERMINAL_COLOR_GREEN}All tests passed!{TERMINAL_COLOR_RESET}")
# exit()
# Compute graph basic building block
class AutoGradNode:
def __init__(self, shape):
# scalar valued gradient accumulator for the final dL/dp
self.shape = shape
self.grad = Tensor(shape)
# dependencies for causation sort
self.dependencies = []
self.materialized = None
def zero_grad(self): zero_kernel(self.grad.buffer, dims_get_total(self.grad.shape))
# Overload operators to build the computation graph
def __add__(self, other): return Add(self, other)
def __mul__(self, other): return Mul(self, other)
def __sub__(self, other): return Sub(self, other)
# Get a topologically sorted list of dependencies
# starts from the leaf nodes and terminates at the root
def get_topo_sorted_list_of_deps(self):
visited = set()
topo_order = []
def dfs(node): # depth-first search
if node in visited:
return
visited.add(node)
for dep in node.dependencies:
dfs(dep)
topo_order.append(node)
dfs(self)
return topo_order
def get_pretty_name(self): return self.__class__.__name__
# Pretty print the computation graph in DOT format
def pretty_print_dot_graph(self):
topo_order = self.get_topo_sorted_list_of_deps()
_str = ""
_str += "digraph G {\n"
for node in topo_order:
_str += f" {id(node)} [label=\"{node.get_pretty_name()}\"];\n"
for dep in node.dependencies:
_str += f" {id(node)} -> {id(dep)};\n"
_str += "}"
return _str
def backward(self):
topo_order = self.get_topo_sorted_list_of_deps()
for node in topo_order:
node.zero_grad() # we don't want to accumulate gradients
set_kernel(self.grad.buffer, 1.0, dims_get_total(self.grad.shape)) # seed the gradient at the output node dL/dL=1
# Reverse the topological order for backpropagation to start from the output
for node in reversed(topo_order):
# from the tip of the graph down to leaf learnable parameters
# Distribute gradients
node._backward()
# The job of this method is to propagate gradients backward through the network
def _backward(self):
assert False, "Not implemented in base class"
# Materialize the numerical value at the node
# i.e. Evaluate the computation graph
def _materialize(self):
assert False, "Not implemented in base class"
# Cache
def materialize(self):
if self.materialized is None:
self.materialized = self._materialize()
assert self.materialized is not None, f"Materialization failed for {self.get_pretty_name()}"
# print(f"Materialized {self.get_pretty_name()}: {self.materialized.shape}")
return self.materialized
# Any value that is not learnable
class Variable(AutoGradNode):
def __init__(self, values, name=None):
assert isinstance(values, Tensor), f"Values must be a Tensor, got {type(values)}"
super().__init__(shape=values.shape)
self.values = values
self.name = name
def get_pretty_name(self):
if self.name:
return f"Variable({self.name})"
else:
return f"Constant()"
def _materialize(self): return self.values
def _backward(self):
pass
Constant = Variable
# Learnable parameter with initial random value 0..1
class LearnableParameter(AutoGradNode):
def __init__(self, shape):
super().__init__(shape=shape)
self.values = Tensor(shape)
set_gaussian_kernel(self.values.buffer, 0.0, 1.0 / shape[-1], random.randint(0, 2**10 - 1), dims_get_total(self.values.shape))
def get_pretty_name(self):
return f"LearnableParameter(shape={self.values.shape})"
def _materialize(self): return self.values
def _backward(self):
pass
class Matrix(AutoGradNode):
def __init__(self, in_channels, out_features):
super().__init__(shape=[out_features, in_channels])
self.values = Tensor([out_features, in_channels])
set_gaussian_kernel(self.values.buffer, 0.0, 1.0 / in_channels, random.randint(0, 2**10 - 1), dims_get_total(self.values.shape))
def get_pretty_name(self):
return f"Matrix({self.values.shape})"
def _materialize(self):
return self.values
def _backward(self):
pass
def transposed(self):
in_features = self.values.shape[1]
out_features = self.values.shape[0]
transposed = Matrix(in_channels=out_features, out_features=in_features)
transpose_kernel(transposed.values.buffer, self.values.buffer, out_features, in_features)
return transposed
def tensor_matrix_multiply(tensor, matrix):
in_features = tensor.shape[-1]
out_features = matrix.shape[0]
assert in_features == matrix.shape[1], f"Incompatible matrix dimensions {tensor.shape} and {matrix.shape}"
result = Tensor(shape=tensor.shape[:-1] + [out_features])
matmul_kernel(result.buffer, tensor.buffer, matrix.buffer, dims_get_total(tensor.shape) // in_features, in_features, out_features)
return result
def tensor_outer_product(tensor_a, tensor_b):
in_features = tensor_a.shape[-1]
out_features = tensor_b.shape[-1]
result_shape = [out_features, in_features] # tensor_a.shape[:-1] + [out_features, in_features]
total_number_of_elems_a = dims_get_total(tensor_a.shape) # we don't really care about the actual shape, for this we know that the tensor is an array of input features
total_number_of_elems_b = dims_get_total(tensor_b.shape) # we don't really care about the actual shape, for this we know that the tensor is an array of output features
assert total_number_of_elems_a // in_features == total_number_of_elems_b // out_features, "Incompatible tensor dimensions for outer product"
result = Tensor(shape=result_shape)
outer_product_accumulate_kernel(result.buffer, tensor_a.buffer, tensor_b.buffer, total_number_of_elems_a // in_features, in_features, out_features)
# outer_product_accumulate_kernel(result.buffer, tensor_b.buffer, tensor_a.buffer, total_number_of_elems_a // in_features, out_features, in_features)
return result
def cpu_tensor_matrix_multiply(tensor, matrix):
in_features = tensor.shape[-1]
out_features = matrix.shape[0]
assert in_features == matrix.shape[1], f"Incompatible matrix dimensions {tensor.shape} and {matrix.shape}"
total_number_of_elems = tensor.size # we don't really care about the actual shape, for this we know that the tensor is an array of input features
np_tensor = tensor.reshape(total_number_of_elems // in_features, in_features)
np_matrix = matrix.reshape(out_features, in_features)
np_result = np.einsum('si,oi->so', np_tensor, np_matrix)
return np_result
def cpu_tensor_outer_product(tensor_a, tensor_b):
in_features = tensor_a.shape[-1]
out_features = tensor_b.shape[-1]
result_shape = [out_features, in_features] # tensor_a.shape[:-1] + [out_features, in_features]
total_number_of_elems_a = tensor_a.size # we don't really care about the actual shape, for this we know that the tensor is an array of input features
total_number_of_elems_b = tensor_b.size # we don't really care about the actual shape, for this we know that the tensor is an array of output features
assert total_number_of_elems_a // in_features == total_number_of_elems_b // out_features, "Incompatible tensor dimensions for outer product"
np_tensor_a = tensor_a.reshape(total_number_of_elems_a // in_features, in_features)
np_tensor_b = tensor_b.reshape(total_number_of_elems_b // out_features, out_features)
np_result = np.einsum('si,sj->ji', np_tensor_a, np_tensor_b)
return np_result
class VectorMatrixMultiply(AutoGradNode):
def __init__(self, tensor, matrix):
assert tensor.shape[-1] == matrix.shape[1], f"Incompatible matrix dimensions: {tensor.shape} vs {matrix.shape}"
super().__init__(shape=tensor.shape[:-1] + [matrix.shape[0]])
self.tensor = tensor
self.matrix = matrix
self.dependencies = [tensor, matrix]
def _materialize(self):
tensor = self.tensor.materialize()
matrix = self.matrix.materialize()
if DEBUG_CPU_EMULATION: # cpu emulation
tensor = tensor.download()
matrix = matrix.download()
result = cpu_tensor_matrix_multiply(tensor, matrix)
return Tensor(shape=result.shape, data=result)
else:
return tensor_matrix_multiply(tensor, matrix)
def _backward(self):
if DEBUG_CPU_EMULATION: # cpu emulation
grad = self.grad.download()
mT = self.matrix.materialize().download().T
tensor = self.tensor.materialize().download()
tensor_grad = cpu_tensor_matrix_multiply(grad, mT)
weight_grad = cpu_tensor_outer_product(tensor, grad)
self.tensor.grad = self.tensor.grad + Tensor(shape=tensor_grad.shape, data=tensor_grad)
self.matrix.grad = self.matrix.grad + Tensor(shape=weight_grad.shape, data=weight_grad)
# self.matrix.grad = self.matrix.grad + tensor_outer_product(self.tensor.materialize(), self.grad)
else:
self.tensor.grad = self.tensor.grad + tensor_matrix_multiply(self.grad, self.matrix.transposed().materialize())
self.matrix.grad = self.matrix.grad + tensor_outer_product(self.tensor.materialize(), self.grad)
class LeakyRelu(AutoGradNode):
def __init__(self, a, negative_slope=0.01):
super().__init__(shape=a.shape)
self.a = a
self.negative_slope = negative_slope
self.dependencies = [a]
def _materialize(self):
x = self.a.materialize()
result = Tensor(x.shape)
leaky_relu_kernel(result.buffer, x.buffer, self.negative_slope, dims_get_total(x.shape))
return result
def _backward(self):
am = self.a.materialize()
slope = Tensor(self.a.shape)
leaky_relu_grad_kernel(slope.buffer, am.buffer, self.negative_slope, dims_get_total(am.shape))
self.a.grad = self.a.grad + self.grad * slope
class Reduce(AutoGradNode):
def __init__(self, a, op='+'):
super().__init__(shape=[1,])
self.a = a
self.dependencies = [a]
self.op = op
assert op in ['+'], "Only sum reduction is supported"
def _materialize(self):
result = Tensor([1,])
reduce_kernel(result.buffer, self.a.materialize().buffer, dims_get_total(self.a.shape))
return result
def _backward(self):
broadcast_add_kernel(self.a.grad.buffer, self.a.grad.buffer, self.grad.buffer, dims_get_total(self.a.shape))
class Square(AutoGradNode):
def __init__(self, a):
super().__init__(shape=a.shape)
self.a = a
self.dependencies = [a]
def _materialize(self):
x = self.a.materialize()
return x * x
def _backward(self):
self.a.grad = self.a.grad + self.grad * 2.0 * self.a.materialize()
class Abs(AutoGradNode):
def __init__(self, a):
super().__init__(shape=a.shape)
self.a = a
self.dependencies = [a]
def _materialize(self):
x = self.a.materialize()
result = Tensor(x.shape)
abs_kernel(result.buffer, x.buffer, dims_get_total(x.shape))
return result
def _backward(self):
sign_tensor = Tensor(self.a.shape)
sign_kernel(sign_tensor.buffer, self.a.materialize().buffer, dims_get_total(self.a.shape))
self.a.grad = self.a.grad + self.grad * sign_tensor
class Sub(AutoGradNode):
def __init__(self, a, b):
assert a.shape == b.shape, f"Incompatible tensor dimensions: {a.shape} vs {b.shape}"
super().__init__(shape=a.shape)
self.a = a
self.b = b
self.dependencies = [a, b]
def _materialize(self):
return self.a.materialize() - self.b.materialize()
def _backward(self):
self.a.grad = self.a.grad + self.grad
self.b.grad = self.b.grad - self.grad
class Add(AutoGradNode):
def __init__(self, a, b):
assert a.shape == b.shape, f"Incompatible tensor dimensions: {a.shape} vs {b.shape}"
super().__init__(shape=a.shape)
self.a = a
self.b = b
self.dependencies = [a, b]
def _materialize(self):
return self.a.materialize() + self.b.materialize()
def _backward(self):
self.a.grad = self.a.grad + self.grad
self.b.grad = self.b.grad + self.grad
class Mul(AutoGradNode):
def __init__(self, a, b):
assert a.shape == b.shape, f"Incompatible tensor dimensions: {a.shape} vs {b.shape}"
super().__init__(shape=a.shape)
self.a = a
self.b = b
self.dependencies = [a, b]
def _materialize(self):
return self.a.materialize() * self.b.materialize()
def _backward(self):
self.a.grad = self.a.grad + self.grad * self.b.materialize()
self.b.grad = self.b.grad + self.grad * self.a.materialize()
class Broadcast(AutoGradNode):
def __init__(self, a, dim, size):
assert dim == 0, f"Only broadcasting in dimension 0 is supported, got {dim}"
input_shape = a.shape[:]
assert input_shape[dim] == 1, f"Input tensor must have size 1 in dimension {dim}"
input_shape[dim] = size
super().__init__(shape=input_shape)
self.a = a
self.dim = dim
self.size = size
self.dependencies = [a]
def _materialize(self):
# Only support [1, N] -> [B, N]
B, N = self.a.shape
assert B == 1, f"Input tensor must have batch size 1, got {B}"
M = self.size
ma = self.a.materialize()
result = Tensor(self.shape)
if DEBUG_CPU_EMULATION:
manb = ma.download()
ranb = result.download()
for i in range(self.size): # Clone the tensor N times
ctypes.memmove(ranb.ctypes.data + i * manb.nbytes, manb.ctypes.data, manb.nbytes)
result = Tensor(self.shape, data=ranb)
return result
else:
# l = dims_get_total(self.a.shape)
for i in range(M): # Clone the tensor N times
copy_kernel(result.buffer, i * N, ma.buffer, 0, N)
# for i in range(self.size): # Clone the tensor N times
# copy_kernel(result.buffer, i * l, ma.buffer, 0, l)
return result
def _backward(self):
# Reduce the gradient
# Only support [B, N]
B, N = self.a.shape
assert B == 1, f"Input tensor must have batch size 1, got {B}"
M = self.size
result = Tensor(shape=[1, N])
if DEBUG_CPU_EMULATION:
grad = self.grad.download()
acc = np.zeros((1, N), dtype=np.float32)
for i in range(M):
acc[0] += grad[i]
self.a.grad = self.a.grad + Tensor(shape=[1, N], data=acc)
return
else:
reduce_broadcast(result.buffer, self.grad.buffer, 1, M, N)
self.a.grad = self.a.grad + result
class AdamW:
"""
Simple AdamW without variance bias correction
"""
def __init__(self, parameters, lr=0.001, betas=(0.9, 0.999), weight_decay=0.01):
self.parameters = parameters
self.lr = lr
self.betas = betas
self.weight_decay = weight_decay
self.moments_1 = []
self.moments_2 = []
for p in parameters:
self.moments_1.append(Tensor(p.grad.shape))
self.moments_2.append(Tensor(p.grad.shape))
def step(self):
for i, p in enumerate(self.parameters):
self.moments_1[i] = self.moments_1[i] * self.betas[0] + p.grad * (1 - self.betas[0])
self.moments_2[i] = self.moments_2[i] * self.betas[1] + (p.grad * p.grad) * (1 - self.betas[1])
p.values -= self.moments_1[i] / (self.moments_2[i].sqrt() + 1e-8) * self.lr
p.values -= p.values * self.weight_decay * self.lr
def get_list_of_live_buffers(self):
return [p.values.buffer for p in self.parameters] + [p.grad.buffer for p in self.parameters] + [p.buffer for p in self.moments_1] + [p.buffer for p in self.moments_2]
if 0: # validation
a = LearnableParameter(shape=[1, 3])
b = LearnableParameter(shape=[1, 3])
m0 = Matrix(in_channels=3, out_features=3)
adamw = AdamW(parameters=[a, b, m0], lr=0.01333, weight_decay=0.0, betas=(0.9, 0.999))
for epoch in range(3000):
x = Variable(Tensor(shape=[1, 3], data=[[random.random(), random.random(), random.random()]]), name="x")
y = VectorMatrixMultiply(Square(x), m0) + b
loss = Reduce(Square(y - (Square(x) * Constant(Tensor(shape=[1, 3], data=[[1.777, 1.333, 0.333]])) + Constant(Tensor(shape=[1, 3], data=[[1.55, 0.0, -1.666]]))))) # L2 loss to Ax^2+B
print(f"Epoch {epoch}: loss = {loss.materialize().download()[0]}; a = {a.materialize().download()}, b = {b.materialize().download()}, \nm0 = \n{m0.materialize().download()}")
# Backward pass
# Gradient reset happens internally in the backward pass
loss.backward()
adamw.step()
exit()
num_input_features = 64
num_nodes = 64
batch_size = 256
num_epochs = 10000
m0 = Matrix(in_channels=num_input_features, out_features=num_nodes)
b0 = LearnableParameter(shape=[1, num_nodes,]) # bias
m1 = Matrix(in_channels=num_nodes, out_features=num_nodes)
b1 = LearnableParameter(shape=[1, num_nodes,]) # bias
m2 = Matrix(in_channels=num_nodes, out_features=num_nodes)
b2 = LearnableParameter(shape=[1, num_nodes]) # bias
m3 = Matrix(in_channels=num_nodes, out_features=3)
b3 = LearnableParameter(shape=[1, 3]) # bias
def broadcast_to_batch(node, batch_size):
return Broadcast(node, dim=0, size=batch_size)
def broadcast_rgb_mul(k, batch_size):
n = np.zeros((batch_size, 3), dtype=np.float32)
n[:, 0] = k
n[:, 1] = k
n[:, 2] = k
return n
def eval_mlp(x):
batch_size = x.shape[0]
z = VectorMatrixMultiply(tensor=x, matrix=m0)
z = z + broadcast_to_batch(b0, batch_size)
z = LeakyRelu(z, negative_slope=0.1)
z = VectorMatrixMultiply(tensor=z, matrix=m1)
z = z + broadcast_to_batch(b1, batch_size)
z = LeakyRelu(z, negative_slope=0.1)
z = VectorMatrixMultiply(tensor=z, matrix=m2)
z = z + broadcast_to_batch(b2, batch_size)
z = LeakyRelu(z, negative_slope=0.1)
z = VectorMatrixMultiply(tensor=z, matrix=m3)
# z = z + broadcast_to_batch(b3, batch_size)
# z = LeakyRelu(z, negative_slope=0.01)
return z
def eval_target(x):
return x * x * 2.777 + 0.624 - x * x * x * 0.333 + np.sin(x * 5.0) * 0.777
adamw = AdamW(parameters=[m0, b0, m1, b1, m2, b2, m3, b3], lr=0.000533, weight_decay=0.01, betas=(0.92, 0.95))
import matplotlib.image as image
ref = image.imread("assets/kodim23.png")[0:512, 0:512, 0:3]
assert ref.shape == (512, 512, 3), f"Unexpected reference image shape: {ref.shape}"
print(f"Reference image shape: {ref.shape}")
# Initialize all the feature vectors for every pixel on the image
size = 512
x_data = np.zeros((size, size, num_input_features), dtype=np.float32)
print(f"Initializing the grid...")
# for pixel_x in range(size):
# for pixel_y in range(size):
# # Frequency encoding
# for i in range(num_input_features // 4):
# x_data[pixel_x, pixel_y, i * 4 + 0] = math.sin(pixel_x * (2.0 ** (i + 1)) * math.pi / size)
# x_data[pixel_x, pixel_y, i * 4 + 1] = math.cos(pixel_x * (2.0 ** (i + 1)) * math.pi / size)
# x_data[pixel_x, pixel_y, i * 4 + 2] = math.sin(pixel_y * (2.0 ** (i + 1)) * math.pi / size)
# x_data[pixel_x, pixel_y, i * 4 + 3] = math.cos(pixel_y * (2.0 ** (i + 1)) * math.pi / size)
L = num_input_features // 4
xx, yy = np.meshgrid(np.arange(size), np.arange(size))
freqs = (2.0 ** (np.arange(L) + 1)) * np.pi / size
x_sin = np.sin(yy[:, :, None] * freqs[None, None, :])
x_cos = np.cos(yy[:, :, None] * freqs[None, None, :])
y_sin = np.sin(xx[:, :, None] * freqs[None, None, :])
y_cos = np.cos(xx[:, :, None] * freqs[None, None, :])
stacked = np.stack([x_sin, x_cos, y_sin, y_cos], axis=-1)
x_data[:] = stacked.reshape(size, size, -1)
print(f"Training...")
for epoch in range(num_epochs):
_x_data = np.zeros((batch_size, num_input_features), dtype=np.float32)
y_data = np.zeros((batch_size, 3), dtype=np.float32)
for b in range(batch_size):
pixel_x = int(random.random() * ref.shape[0])
pixel_y = int(random.random() * ref.shape[1])
_x_data[b] = x_data[pixel_x, pixel_y]
y_data[b, 0] = ref[pixel_x, pixel_y, 0]
y_data[b, 1] = ref[pixel_x, pixel_y, 1]
y_data[b, 2] = ref[pixel_x, pixel_y, 2]
x = Variable(Tensor(shape=[batch_size, num_input_features], data=_x_data), name="x")
mlp = eval_mlp(x)
loss = Reduce(Square(mlp - Constant(Tensor(shape=[batch_size, 3], data=y_data))), op='+')
if epoch == 0:
with open(".tmp/graph.dot", "w") as f:
f.write(loss.pretty_print_dot_graph())
# Backward pass
# Gradient reset happens internally in the backward pass
loss.backward()
adamw.step()
queue.flush()
print(f"Epoch {epoch}: loss = {loss.materialize().download()[0] / batch_size}; lr = {adamw.lr}")
adamw.lr *= 0.99999
# Poor mans garbage collection.
# Only keep the leaf nodes of the graph
# keep_alive_buffers = adamw.get_list_of_live_buffers()
# for size in allocated_tensor_pool.keys():
# for buffer in allocated_tensor_pool[size]:
# if buffer not in keep_alive_buffers:
# free_buffer(buffer, size)
print(f"Allocated buffers: {get_number_of_allocated_buffers()}")
print(f"Free buffers: {get_number_of_free_buffers()}")
# Plot our mlp
import matplotlib.pyplot as plt
x_data = x_data.reshape((size * size, num_input_features))
x = Variable(Tensor(shape=[size * size, num_input_features], data=x_data), name="x")
y_data = eval_mlp(x).materialize().download().reshape((size, size, 3))
plt.imshow(y_data, aspect="auto")
plt.axis("off")
plt.show()
Links
[1]PyOpenCL
